Soft Fibre Ceiling Canopy
Armstrong Soundscapes Basics
Soundscapes Basics can define modern and grand spaces&Excellent acoustical qualities,which provide outstanding acoustical performance in open plan areas such as offices, classrooms, theatres & auditoriums.
Materials & Options
Traffic White
RAL co-ordinated
Lay-in
Square tegular
Angled tegular
K2C2
SL2
Please refer to datasheet for full list of modules
Technical specifications
Features
- Excellent acoustical qualities
- Refined visual appearance
- High durability, high light reflectance, high sag resistance
- Ceiling qualifies for LEED credits and certified with China Green Product Label
Application Areas
- Office
- Healthcare
- Retail
Performance
Sound Absorption
NRC = 0.85（25mm）；NRC0.80（20mm）；NRC0.75（15mm）
Light Reflectance
88%% (for Traffic White shade)
Fire Reaction
Class A2 -s1, d0 as per GB 8624-2006
Weight
Dependent on size and shape
0.75kgs - 4.87kgs
600X600X15mm：0.75（kg/pcs)
600X1200X15mm: 1.50（kg/pcs)
1200X1200X20mm:4（kg/pcs)
1200X1200X25mm:.4.87（kg/pcs)
0.75kgs - 4.87kgs
600X600X15mm：0.75（kg/pcs)
600X1200X15mm: 1.50（kg/pcs)
1200X1200X20mm:4（kg/pcs)
1200X1200X25mm:.4.87（kg/pcs)
Humidity Resistance
RH 99%
Recycled Content
Up to 85%
