Metal Ceiling Baffle
Armstrong Metalworks V-P 500
MetalWorks V-P 500 Acoustical Baffles provide modern linear apearance. Excellent acoustic perfomance, flexible sizes and configurations. Highly customisable options & finishes. Robust, engineered system. Quick and easy to install.
Materials & Options
Global White
Global White（Bioguard）
RAL 9003
RAL 9016
RAL 9010
RAL 9006
RAL colors available on request
Wood grain effects available on request
Extra-micro perforation M11 (3% Open area)
Micro Perforation M9 (9.6% Open area)
Micro Perforation M2 (19.1% Open area)
Unperforation M1
2000/3000x100x30 - 2000/3000x100x50
2000/3000x150x30
2000/3000x200x30
2000/3000x250x50
2000/3000x350x50
2000/3000x300x30
2000/3000x400x30
2000/3000x450x50
Technical Specifications
Features
- Excellent acoustic performance
- Modern linear appearance
- Flexible sizes and configurations
- Customisable options & wood finishes
- Robust, engineered system
- Quick installation & easy maintance
Application areas
- Transportation
- Retail
- Education
- Corridors and Open plan
- Office
Performance
Sound Absorption
NRC0.60
Sabin：0.73
Sabin：0.73
Fire Reaction
GB8624-2012 Glass A
Weight
Galvanised Steel ≅ 5.53 kg/m²
Humidity Resistance
Up to RH99%
Recycled Content
Up to 30%
