Metal Ceiling Tile

Armstrong Metalworks R-H 200

MetalWorks R-H 200 is a versatile custom metal plank design suitable for regular & staggered patterns. All panels are fully accessible without the use of tools. Available in a variety of sizes, perforations & finishes.

Available in: China
  • China

Materials & Options

Global White
Global White(Bioguard)
RAL 9003
RAL 9016
RAL 9010
RAL 9006
RAL colors available on request
Wood grain effects available on request
Unperforation M1
Extra Micro Perforation M11 (3% Open area)
Micro Perforation M9 (9.6% Open area)
Micro Perforation M2 (19.1% Open area)
Extra Micro Perforation M3 (1.5% Open area)
Extra Micro Perforation M8 (2% Open area)
Standard Perforation M10(16% Open area)

Technical Specifications



  • Hook-on is more flat and stable
  • Rolling forming J-bar with higher system intensity
  • Flexible personalized customization service

Application areas

  • Transportation
  • Retail
  • Education
  • Healthcare
  • Office


Sound Absorption
NRC 0.70
Fire Reaction
GB8624-2012 Glass A
Galvanised Steel ≅ 7.12 kg/m²
Aluminium ≅ 12.21 kg/m²
Humidity Resistance
Up to 99% RH
Recycled Content
Up to 30%

Downloads &Contact

Our proactive, service-driven mentality stands out just as much as our products. We have the technical know-how to provide specialist consulting expertise, as well as the feet on the ground to deliver the custom solutions you need on-site.
