Metal Ceiling Tile
Armstrong Metalworks Accoustical Infill
16 mm mineral fibe Mills solution significantly optimizes the sound attenuation performance (CAC) room to room.
20 mm fiberglass infills solution empowers excellent sound absorption capability (NRC) for indoor environment.
Materials & Options
Global White
Global White（Bioguard）
RAL 9003
RAL 9016
RAL 9010
RAL 9006
RAL colors available on request
Wood grain effects available on request
Unperforation M1
Standard Perforation M10 (16% Open area)
Micro Perforation M9 (9.6% Open area)
Micro Perforation M2 (19.1% Open area)
Acoustical Perforation (Rv3136）
600 x 600 mm
1200 x 300 mm
1200 x 400 mm
1200 x 600 mm
Technical Specifications
Features
- Factory bonded solution reduces 'pattern staining' associated with incorrectly fitted acoustic pads.
- Excellent anti-humidity & fire reaction ensure.
Application areas
- Office
- Healthcare
- Education
- Hospitality and retail
- Transportation
Performance
Sound Absorption
NRC = 0.60 (16mm MF Infill)
NRC = 0.85 (20mm FG Infill)
NRC = 0.9（15mm FG Infill）
NRC = 0.85 (20mm FG Infill)
NRC = 0.9（15mm FG Infill）
Sound Attenuation
CAC up to 39 dB（16mm MF Infill）
Fire Reaction
GB8624-2012 Glass A
Recycled Content
Up to 30%
Humidity Resistance
Up to RH99%
