Mineral Ceiling Tile
Armstrong ULTIMA+
Armstrong ULTIMA+ offers a smooth, modern, white appearance and is the optimal solution for area that need outstanding noise absorption
Materials & Options
Armstrong ULTIMA+
600 x 600 mm
1200 x 600 mm
Board Edge Detail
Tegular 24 Edge Detail
Tegular 15/90 BE Edge Detail
Technical specifications
Features
- Excellent sound absorption NRC 0.70
- Excellent sound attenuation (35 dB)
- Good light reflectance (88%)
Application Areas
- Ideal for Office, Retail, Healthcare, Education environments
Performance
Sound Absorption
NRC = 0.70
Sound Attenuation
CAC 35 (BOARD)
Light Reflectance
88%
Fire Reaction
US: Class A-Flame Spread 25 or Under
BS476 part 6 & 7 Class 0 / Class 1
Class A(China standard-GB/T 14402)
BS476 part 6 & 7 Class 0 / Class 1
Class A(China standard-GB/T 14402)
Weight
5.32 kgs/m²
(1.09lbs/SF)
(1.09lbs/SF)
Thermal Conductivity
R Factor-1.70(BTU units)
R Factor-0.30(Watts units)
R Factor-0.30(Watts units)
Humidity Resistance
RH99
Clean Room
Class 5 as per ISO 14644-1
Recycled Content
42%
Cleaning
Washable
diluted detergent
diluted detergent
