Mineral Ceiling Tile

Armstrong ANF

Armstrong ANF is a value-for-money product with a structured and ground surface

Contact us
Available in: China
China
  • China

Materials & Options

Armstrong ANF
600 x 600 mm / 24" x 24"
1200 x 600 mm / 48" x 24"
Board Edge Detail
Tegular 24 Edge Detail
Tegular 15 BE Edge Detail

Technical specifications



产品特色

  • Excellent light reflectance (85%)

Application Areas

  • Ideal for retail environments

Performance

Sound Absorption
NRC = 0.50
Sound Attenuation
CAC = 30 dB (BOARD)
Light Reflectance
85%
Fire Reaction
US: Class A-Flame Spread 25 or Under
BS476 part 6 & 7 Class 0 / Class 1
GB8624-2012 B1
Weight
3.5 kgs/m²
(0.72 lbs/SF)
Thermal Conductivity
R Factor-1.5(BTU units)
R Factor-0.26(Watts units)
Humidity Resistance
RH90
Clean Room
-
Recycled Content
41%

Datasheet

DS_ANF_EN.pdf
pdf | 302 KB
